Vonyx WK10 10cm Wide-Range Woven Cone Speaker 75W RMS
Quantity:
The Vonyx WK10 is a 4-inch wide-range bass speaker designed for hi-fi speaker projects. Its smoothly suspended woven cone and rubber surround support reliable peak-load handling, while the vented, heat-resistant four-layer voice coil provides added durability.
Rated at 75W RMS and 150W maximum output, the driver features an 8-ohm impedance, 1-inch voice coil and ferrite magnet. A 92mm mounting diameter and 60mm mounting depth provide clear measurements for installation planning.
- Woven cone with smooth suspension
- Vented, heat-resistant four-layer voice coil
- Durable rubber surround
- Large ferrite magnet
- 75W RMS and 150W maximum output
- 8-ohm impedance
- Product colour
- Yellow
- Maximum output power
- 150W
- RMS output power
- 75W
- Woofer diameter
- 4 inches
- Voice coil
- 1 inch
- Magnet type
- Ferrite
- Magnet weight
- 10oz
- Frequency response
- 66Hz–9,000Hz
- SPL at 1W/1m
- 82dB
- Impedance
- 8 ohms
- Mounting diameter
- 92mm
- Mounting depth
- 60mm
- Dimensions (L × W × H)
- Ø113 × 65mm
- Weight
- 0.65kg
